Cheap Cnc Surface Grinding Machine wholesale quotes

Features: The control system adopts FANUC numerical control system, which can realize continuous dressing, automatic compensation, and automatic processing of the grinding wheel during the grinding operation, and can use the full closed loop feedback of the optical ruler to complete the high-precision grinding operation setting set. Machine characteristics  The vertical accuracy of horizontal plane and vertical plane is controlled below 0.002mm. CNC series grinders are especially suitable for linear slides and sliders, high-precision molds and other grinding operations with strict vertical accuracy requirements. Equipped with a dynamic pressure spindle with high rigidity, low vibration and high cutting ability to ensure the precision performance of grinding and honing. Reinforced rib box design. This machine uses Mihana casting to ensure high rigidity and stability of the machine. Manual high-precision spade flowers, wear-resistant patches and dynamic pressure lubrication system ensure machine quality and service life. C1 grade ball screw due to the characteristics of static pressure lubrication, can reduce the interaction of friction, and can increase rigidity and positioning accuracy, the minimum feed is within 0.1um. When the lubrication system is operating, the oil supply guide rail and lead screw of the automatic circulation lubrication system ensure that all key parts can be properly lubricated at any time. All high-precision spindles are installed by experienced technicians in a constant temperature and dust-free workshop. They are matched with P4 super-precision angular contact ball bearings and pre-pressed. The bearings are combined with special options and balanced shaft cores to ensure the spindle Beating within 0.002mm, low temperature rise, low beating, low vibration, high precision grinding

1. The main castings of the machine tool are made of high-grade cast iron. After annealing and vibration aging treatment, the internal stress of the casting is removed, the stability of the casting is greatly improved, and it is not easy to deform;

2. In order to improve working efficiency, the company's machine tools are thick in material and stable in body, which meets the rigidity requirements of heavy cutting and precision grinding;

3. The guide rails are affixed with high-grade imported wear-resistant rubber, which is precision-shoveled by hand to ensure long-lasting accuracy;

4, X, Y axis full plane accuracy 0.005mm;

Technical parameters

Worktable working area 300 × 600 mm

Left and right movement 720 mm

360 mm

Distance from table to spindle center 605 mm

Maximum table load 400 KG

Table T-slot 14 × 1 mm × N

Table speed 5 ~ 25 m / min

Front and rear hand wheel feed (1 division / 1 turn) 0.02 / 5 mm

Front and rear automatic feed 0.1-8 mm

Fast forward and backward movement (50HZ / 60HZ) 990/1190 mm / min

Grinding wheel size Φ350 × 40 × 127 mm

Grinding wheel speed (50HZ / 60HZ) 2850 RPM

Up and down handwheel feed (1 division / 1 turn) 0.005 / 5 mm

Up and down rapid moving speed 230 mm / min

Spindle motor 2x2 HXP

80 W motor power

Hydraulic motor 2 × 6 HxP

Cooling motor power 90 W

Front and rear drive motor power 80 W

Machine dimension 2000 * 1900 * 1800 mm

Machine weight 2200 KG
